RV Electronics Black RV LED Double Water Gauge

The RV Electronics Double Water Level Indicator has been designed to give an accurate reading of the water level in the on board water tanks of caravans, travel trailers, motorhomes, campers and boats

One of the most important features of this product is its ease of installation. The tank sender probe is installed into the side of the water tanks, making it unnecessary to remove the water tank from its mounting. The sender probe has no moving parts and measures the water level by water contact with the 5 sensors along the arm. LED water level indicators check the water level with a simple push button. Easy to read 5 bar display.

You now have the ability to customise the kit to suit your requirements with a range of single, double and triple tank gauges to be matched with the 2.5, 5, or 7.5 metre lead sender probes.

There is no need to wire in a 12 volt supply as the top indicator gauge comes complete with its own battery, which is easily replaced when the need arises. The water gauge measures only 64mm H x 64mm W x 11mm D, so it is small enough to fit any application. This easy to fit tank sender probe only requires one 22mm (7/8″) hole in the side of the tank and suits tanks from 100mm to 280mm (4″ to 11″) deep. The sender probe is sealed by a special grommet which is compressed in the hole when the nut is tightened and measures the water level by contact with the 5 sensors along the arm.

FEATURES AND BENEFITS:

• Battery operated – 12V A23 (Included)
• Made in Australia
• 1 Year Warranty

SPECIFICATIONS:

• Part number – SWG0325
• 64 x 64 x 11 mm
• Please note: Sender probe not included
• Installation Instructions, click here

WHAT IS INCLUDED:

• 1 x RV Electronics Black RV LED Double Water Gauge
